High Strength H Section Steel Structure Workshop Building Fabrication
Product Description
| Material: |
Weld/hot Rolled H Beam, C/Z Steel |
Grade: |
Q235B,Q345B,G550 |
| Application: |
Steel Workshop,warehouse |
Place Of Origin: |
Shandong,China(mainland) |
| Design: |
As Customer's Request |
Anti-seismic: |
8.0 |
| Surface: |
Painting/galvanized |
Wall/roof: |
Sandwich Panel/color Steel Sheet |
| High Light: |
steel building workshop
,
structural steel workshop
|
2. Specification
| Items |
Specification |
| Main Steel Frame |
Column |
Q235, Q345 Welded H Section Steel |
| Beam |
Q235, Q345 Welded H Section Steel |
| Secondary Frame |
Purlin |
Q235 C and Z purlin |
| Knee brace |
Q235 Angle Steel |
| Tie Rod |
Q235 Circular Steel Pipe |
| Brace |
Q235 Round Bar |
| Vertical and Horizontal Support |
Q235 Angle Steel, Round Bar or Steel Pipe |
| Maintenance system |
Roof Panel |
EPS Sandwich Panel / Glass Fiber Sandwich Panel /
Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet |
| Wall Panel |
Sandwich Panel / Corrugated Steel Sheet |
| Accessories |
Window |
Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window |
| Door |
Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door |
| Rainspout |
PVC |
| Live load on Roof |
In 120kg/Sqm (Color steel panel surrounded) |
| Wind Resistance Grade |
12 Grades |
| Earthquake-resistance |
8 Grades |
| Structure Usage |
Up to 50 years |
| Finishing Options |
Vast array of colors and textures available |
| Paint Options |
Alkyd paiting, two primary painting, two finish painting
(gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized. |
3. Characteristics
1. Wide span: single span or multiple spans, the max span is 36m without middle column.
2. Low cost and maintenance: unit price range from USD35/m2 to USD70/m2 according to customers request.
3. Fast construction and easy installation: time saving and labor saving.
4. Long using lifespan: up to 50 years.
5. Nice appearance.
6. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.
Specifications
| Main steel frame: |
Prefabricated construction design steel structure warehouse |
| Steel frame brace: |
tie bar, roof and wall bracing, brace, knee bracing, casing pipe |
| Wall Panel: |
50mm/75mm/100mm sandwich board(with EPS, PU, glass wool, rock wool, etc for its interlayer) |
| Roof Panel: |
50mm/75mm/100mm sandwich board(with EPS, PU, glass wool, rock wool, etc for its interlayer) |
| Windows: |
Aluminum alloy window or plastic steel windows |
| Doors: |
Sandwich board door or aluminum alloy door |
| Fasteners: |
anchor bolt, high strength bolt, general bolt, nut, washer etc |
Specifications For Wall And Roof Panel
| EPS sandwich panel |
|
| EPS sandwich panel(50mm,75mm,100mm) |
| Width of panels |
950mm/1150mm |
| Lengths of panels |
customized |
| Thickness of color steel plate |
0.3-0.5mm |
| Specific gravities |
8-16Kg |
| Resistances of heat-transfer process |
0.035-0.05w/m.k |
| Sound deadening |
|
| Limits of fire resistance |
None |
| Rock wool sandwich panel |
|
| Rockwool sandwich panel(50mm,75mm,100mm) |
| Width of panels |
950mm/1150mm |
| Lengths of panels |
customized |
| Thickness of color steel plate |
0.3-0.5mm |
| Specific gravities |
10.2-17.7Kg/ |
| Resistances of heat-transfer process |
≤0.044w/m.k |
| Sound deadening |
21.5db |
| Limits of fire resistance |
Grade A incombustible |
| PU sandwich panel |
|
| PU sandwich panel (50mm,75mm,100mm) |
| Width of panels |
950mm/1150mm |
| Lengths of panels |
customized |
| Thickness of color steel plate |
0.3-0.5mm |
| density |
≥30Kg/m3 |
| Water absorption for 24 hours |
≤1 |
| thermal conductivity |
≤0.023w/m·k |
| compressive strength |
≥200kpa |
| fire proof rate |
B1
|
>> Characteristics:
| Main Parts |
Item Name |
Specification |
| Main Steel Frame |
Steel Column |
Q235B, Q345B
H shape, Box, Steel pipe, Hot rolled sheet
|
| Steel Beam |
Q235B, Q345B
H shape, Steel Truss, Hot rolled sheet
|
| Supporting System |
Brace |
Q235B, Q345B
Steel rod, Steel pipe, Angle steel
|
| Roof Purlin |
C or Z shape, Steel purlin |
| Wall Purlin |
Q235B, Q345B
C or Z shape, Steel purlin
|
| Roof |
Single colorful corrugate steel sheet, Sandwich panel with EPS, Rock wool, PU, Glass wool etc., |
| Wall |
Single colorful corrugate steel sheet, Sandwich panel with EPS, Rock wool, PU, Glass wool etc., |
| Accessories |
Bolts |
Ordinary, High strength |
| Gutter |
Galvanized Steel plate, Stainless steel |
| Windows |
Aluminum alloy-Glass, Aluminum alloy-shutter, PVC |
| Doors |
Sliding or Rolling door |
| Downpipes |
PVC pipe, Color steel pipe |
| Edge Cover |
Made of color steel sheet thickness 0.5mm |
| Ventilator |
Stainless steel |
| Crane |
Crane in 5 tons to 20 tons |
>> Construction Advantage
| Fast construction |
Steel structure members are pre-welded, pre-drilled and pre-punched in our factory. Only need to connect by bolts with the accuracy of steel components, no need weld on construction field.
Only need 5 workers to assemble one steel structure building of 1000 sqm within 25 days. |
| Affordable cost |
Require less maintenance than concrete building. Averagely, it cost about 50% less than traditional construction. Moreover, 98% of all steel structure can be recycled into new steel products without reducing physical properties. |
| Anti-seismic and wind resistance |
Can withstand grade 8 earthquake, wind resistance 300km/h. |
| Long service time |
More than 50 years. |
| Health and safety |
Steel structure building is manufactured at the factory and rapid installation on the construction site by skilled personnel making steel structure safe. There is very little noise and dust. |
>> Installation options:
There are 3 options of installation as following:
1. Clients install it by themselves according our construction drawings and online gaidance service.
2. Our engineer to help you on construction site.
3. We provide installation team to help.
Detailed Images
Part of our products:
Company Profile:
Established in 2014, the company is a high-tech, diversified and export-oriented large-scale international
private enterprise integrating R&D, design, production, installation and construction at home and abroad,
and technical services.
It has the qualification certificate of overseas contracted project management issued by the Ministry of
Commerce of China, CE certification [EN1090 certificate], IS09001 certificate, etc, and has long-term
cooperation with countries along the " Belt and Road".
The products and construction services have been exported to more than 50 countries around the world,
including Asia, Africa, North and South America. In addition, branches have been established in
Mozambique and Angola, which can undertake steel structure installation projects in Africa.
Products& Services:
Gusite's main products include steel structure industrial buildings, commercial buildings,airports, stadiums, greenhouses, light steel houses, livestock breeding houses, interior and exterior decoration materials, various doors and windows, etc.
It has its own design team which can provide customized design. lt can also produce series of steel structure products with different structures and specifications. lt has complete processing and manufacturing equipment and strong installation capabilities. lt can supply a full set of materials required for steel structure construction projects, and provide all installation services and technical consultations.
Production Capacity:
Qualification certificates:
Philosophy& Vision:
Since its establishment,Gusite has been constantly seeking sustainable development and has created value for society and customers with the service tenet of "Quality first. Customer first"Facing the current good situation of the booming international economy, with brand-new concepts scientific management and high-quality services, the company strictly follows the development idea of market-oriented, large-scale and scientific", doing a good job in the present, focusing on the future, and striving to move forward to the ranks of the first-class construction enterprises in the country.
