Product Description:
Steel structure workshop is the type of building formed by main framework which mainly consists of steel column, steel beam and purlin, thus the steel structure accounts for the major load-bearing member of steel workshop building. The roof and wall of steel workshop utilize various styles of panels that will overlap when assembled together, leaving no openings. As a result, the steel frame structure workshop can be isolated against outdoor environments. Due to reasonable cost and short construction period, steel structure has been applied in a wide range of industrial and non-industrial building construction.
Features:
1. Compared with ordinary reinforced concrete structures,metal workshop construction have the advantages of homogeneity, high strength, fast construction speed, good seismic resistance and high recovery rate. The strength and elastic modulus of steel are many times higher than those of masonry and concrete. Therefore, Under the same load conditions, the weight of steel members is light. From the perspective of damage, the steel structure has a large deformation omen in advance, which belongs to the ductile failure structure, which can detect the danger in advance and avoid it. 2. The steel structure workshop metal steel building has the advantages of overall light weight, saving foundation, less materials, low cost, short construction period, large span, safety and reliability, beautiful appearance and stable structure. Steel structure workshops are widely used in construction industries such as large-span industrial plants, warehouses, cold storages, high-rise buildings, office buildings, multi-storey parking lots and residential buildings. 3. Steel may be made and delivered in a cost-effective and timely manner. Steel structures metal frame buildings can be handed off- the point at shop floors and after that gathered hard. This spares time and increases the effectiveness of the general development process.
Technical Parameters:
| Parameter | Description |
| Column and Beam | Q355 Welded H Section Steel |
| Downpipe | UPVC |
| Drawing design | AutoCAD,PKPM,MTS,3D3S,Tarch,Tekla Structures |
| Size | Customized |
| Crane | Optional |
| Window | Aluminum Alloy/Plastic Steel |
| Purlin | C Section/Z Section |
| Door | Rolled Up Door/Sliding Door |
| Surface Treatment | Painted/Hot Dip Galvanized |
| Structure | Steel Structure |
Applications:
The single-story Steel Structure Workshop is the primary type of workshop and warehouse in Metallurgy, machinery, and other industries. Many workshops choose a single-story steel structure workshop mainly because of its large span and the height that can adjust to the need.
The production of the multi-story steel structure workshop is carried out on different elevation floors, with a horizontal connection between each floor and a vertical connection. Therefore, in the design of the factory building, it is not only necessary to consider the reasonable connection between the sections on the same floor and to solve the vertical connection between floors and arrange the traffic in the vertical direction.
Company profile: Qingdao Gusite Construction Technology Co, Ltd. was established in 2014. lt is a high-tech, diversified and export-oriented large-scale international private enterprise integrating R&D, design, production, installation and construction at home and abroad, and technical services.
Gusite has the qualification certificate of China's overseas contracted project management issued by the Ministry of Commerce of China, CE certification [EN1090 certificatel), ISO9001 certificate, etc, and has carried out long-term cooperation with countries along the "Belt and Road". The current products and construction services have been exported to more than 50 countries around the world, including Asia, Africa, North and South America. ln addition. branches have been established in Mozambigue and Angola, which can undertake steel structure installation projects in Africa
Production process:
Qualification certificates:
Support and Services:
Steel Structure Workshop Technical Support and Service
Our team of experts is committed to providing the highest level of technical support and service for your steel structure workshop. Our team of experienced professionals is available to answer any questions you may have and to provide technical advice on any aspect of your steel structure workshop.
We offer a range of services, including on-site installation and maintenance, as well as remote support for your steel structure workshop. Our team is also available to assist you in the design and engineering of your steel structure workshop, as well as providing advice on the best materials and components to use.
For more information about our steel structure workshop technical support and service, please contact us today.
Packing and Shipping:
Our technical team will do the economical packing plan for clients, calculate the quantity of steel structure materials accurately and use the min. quantity of containers, to save the shipping freight for clients.
When packing we use the pallets according to container's size, to improve the loading unloading efficency.
